AR:One
Zephyr SSL Handlebar Included!
Regular price
$3,099.00 AUD
Sale price
$3,099.00 AUD
Regular price
Unit price
AR:One
Meet the AR:ONE
The do-it-all road bike. From hills to flat terrain, the AR:One is undoubtedly quick.
Discover what makes the AR:ONE an all-round road weapon.
UCI Approved Race Bike
Advanced material – built with premium Toray T1100 and M56 high grade carbon fibers
All round road weapon
Lightweight integrated bar
Customisable componentry.
Your bike, your way
Find Your AR:One Fit
Rider Size Guide
Use your rider height
to find your ideal
AR:One frame size.
XS
5’01” to 5’05”155–165 cm
SM
5’04” to 5’08”163–173 cm
MD
5’07” to 5’11”170–180 cm
LG
5’10” to 6’02”178–188 cm
XL
6’01” to 6’04”185–193 cm
XXL
6’03” to 6’06”190–198 cm
Frame Size
Geometry Diagram
Key frame measurements
that define fit, handling
and ride feel.
| XS / 430 | S / 460 | M / 490 | L / 520 | XL / 550 | XXL / 580 | ||
|---|---|---|---|---|---|---|---|
| A | Frame Size / Seat Tube Length (mm) | 430 | 460 | 490 | 520 | 550 | 580 |
| B | Effective Top Tube Length (mm) | 510 | 525 | 540 | 555 | 570 | 589 |
| C | Seat Tube Angle (°) | 75.0 | 74.5 | 74.0 | 73.5 | 73.5 | 73.5 |
| D | Head Tube Angle (°) | 70.0 | 71.0 | 72.0 | 73.0 | 73.0 | 73.5 |
| E | Head Tube Length (mm) | 105 | 115 | 130 | 145 | 160 | 180 |
| F | Chainstay Length (mm) | 408 | 408 | 408 | 408 | 408 | 408 |
| G | Wheelbase (mm) | 982 | 984.5 | 986 | 987 | 1002 | 1013.7 |
| H | Fork Offset / Rake (mm) | 50 | 50 | 45 | 45 | 45 | 45 |
| I | Bottom Bracket Drop (mm) | 71.65 | 71.65 | 71.65 | 71.65 | 71.65 | 71.65 |
| J | Fork Length (mm) | 370 | 370 | 370 | 370 | 370 | 370 |
| K | Standover Height (mm) | 710.5 | 736 | 761.5 | 787 | 812.5 | 837 |
| L | Stack-to-Reach Ratio (STR) | 1.34 | 1.35 | 1.38 | 1.41 | 1.41 | 1.42 |
| — | Reach (mm) | 375.37 | 382.17 | 386.71 | 391.4 | 402 | 412.3 |
| — | Stack (mm) | 503.9 | 516.73 | 534.57 | 552 | 566.5 | 587.7 |
